Description
Specifications:
- Channel: Dual, isolated between channels
- Modes of Operations: Continuous, Burst, Modulation
- Pulse Intensity: Adjustable 0-80mA peak into 500 ohm load each channel, constant current
- Pulse Rate: 2Hz-150Hz (adjustable)
- Pulse Width: 30μs – 260μs (adjustable)
- Time: Continuous, 30 min, 60 min
- Burst Mode: Burst consists 2 bursts per sec at 100 Hz
- Wave Form: Asymmetrical Bi-Phasic square pulse
- Voltage: 0-100 Volt (open current)
- Power Source: 9 volt battery
- Dimensions: 95(H) x 60(W) x 23(D) mm
- Weight: 115 grams (battery included)
Additional information
ARTG Number | 143382 |
---|
